Experimental Performance Analysis of A Solar Hybrid Recirculating Mixed-Flow Dryer With Different Drying Temperatures For Drying Paddy

Muhammad Yahya; Dedi Wardianto; P Pratiwi

doi:10.24036/ijimce.v2i1.56

Authors

Muhammad Yahya Departemen of Mechanical Engineering, Institut Teknologi Padang, INDONESIA
Dedi Wardianto Departemen of Mechanical Engineering, Institut Teknologi Padang, INDONESIA
P Pratiwi Departemen of Mechanical Engineering, Institut Teknologi Padang, INDONESIA

DOI:

https://doi.org/10.24036/ijimce.v2i1.56

Keywords:

Paddy, drying, mixed-flow dryer, solar hybrid, performance

Abstract

This study is focussed on the performance of a solar hybrid recirculating mixed-flow dryer (SHRMFD) for drying paddy with different drying air temperatures. The drying experiments were carried out at average air temperatures of 50 °C, 60 °C and 70 °C. The SHRMFD reduced the mass of paddy from 420 kg (16.90% wb) to 406.07 kg (14.17% wb) in 360 min; from 420 kg (16.80 % wb) to 407.63 kg (14.17%) in 165.4 min; from 420 kg (16.75 % wb) to 407.35 kg (14.17% wb) in 143.3 min for average air temperatures of 50°C, 60°C and 70°C, respectively. The highest drying rate (3,324 kg/hour) was achieved at an average air temperature of 70°C. The specific moisture evaporation rate (0.171kg/kWh) and thermal efficiency of SHRMFD (25.04%) were achieved highest at an average air temperature of 50°C. The lowest specific energy consumption (11.804 kWh/kg) was achieved at an average air temperature of 50°C. The energy contributed by the biomass furnace and the solar collector for SHRMFD were 13.28 and 14.74%; 8.08 and 17.50%; and 6.10 and 20.35 for average air temperatures of 50°C, 60°C and 70°C, respectively. The SHRMFD performance is better at an average air temperature of 50°C because it has higher thermal efficiency and lower energy consumption.

Downloads

Download data is not yet available.

References

BPS (Badan Pusat Statistik Indonesia), “Statistik Indonesia,” Jakarta, 2019.

C. Bonazzi, F. Courteis, C. Geneste, M.C. Lahon, and J. Bimbent, “Influence of drying conditions on the processing quality of rough rice,” Dry. Technol. vol. 51, no. 3, pp. 1141-1157, 1997.

BSN (Badan Standardisasi Nasional), “Standar Nasional Indonesia Beras Giling, SNI 6128: 2008,” Badan Standardisasi Nasional, Jakarta, pp. 9, 2008.

R. Thahir, “Pengaruh aliran udara dan ketebalan pengeringan terhadap mutu gabah keringannya,” Buletin Enjiniring Pertanian VII (1&2), pp.1-5, 2000.

M. Yahya, H. Fahmi, and H. Hasibuan, “Experimental performance analysis of a pilot-scale biomass-assisted recirculating mixed-flow dryer for drying paddy,” International Journal of Food Science, pp. 1-15, 2022.

M. Yahya, “Design and performance evaluation of a solar assisted heat pump dryer integrated with biomass furnace for red chilli,” International Journal of Photoenergy, pp. 1-14, 2016.

E.K. Akpinar, “Drying of mint leaves in a solar dryer and under open sun: Modelling, performances analyses,” Energy Conversion and Management, vol. 51, pp. 2407-2418, 2010.

M. Yahya, A. Rachman, and R. Hasibuan, “Performance analysis of solar-biomass hybrid heat pump batch-type horizontal fluidized bed dryer using multi-stage heat exchanger for paddy drying,” Energy, vol. 254, pp. 124294, 2022.

M.S.H. Sarker , M. N. Ibrahim , N. Ab. Aziz, and P. M. Salleh, “Energy and rice quality aspects during drying of freshly harvested paddy with industrial inclined bed dryer,” Energy Conversion and Management, vol. 77, pp. 389-395, 2014.

M. Yahya, H. Fahmi, A. Fudholi, and K. Sopian, “Performance and economic analyses on solar-assisted heat pump fluidised bed dryer integrated with biomass furnace for rice drying,” Solar Energy, vol. 174, pp. 1058–1067, 2018.

A. Fudholi, K. Sopian, M.Y. Othman, and M.H. Ruslan, “Energy and exergy analyses of solar drying system of red seaweed,” Energy and Building, vol. 68, pp. 121-129, 2014.

A. Fudholi, K. Sopian, M.Y. Yazdi, M.H. Ruslan, M. Gabbasa, and H.A. Kazem, “Performance analysis of solar drying system for red chili,” Solar Energy, vol. 99, pp. 47-54, 2014.

J. Banout, P. Ehl, J. Havlik, B. Lojka, Z. Polesny, and V. Verner, “Design and performance evaluation of a Double-pass solar drier for drying of red chilli (Capsicum annum L.),” Solar Energy, vol. 85, no.3, pp. 506–515, 2011.

S. Sevik, “Experimental investigation of a new design solar-heat pump dryer under the different climatic conditions and drying behavior of selected products,” Solar Energy, vol. 105, pp. 190-205, 2014.

E.K. Akpinar, “Drying of mint leaves in solar dryer and under open sun: Modelling, performance analyses,” Energy Conversion and Management, vol. 51, pp. 2407-2418, 2010.

A. Fudholi, K. Sopian, M.A. Alghoul, M.H. Ruslan, and M.Y. Othman, “Performances and improvement potential of solar drying system for palm oil fronds,” Renewable Energy, vol. 78, pp. 561-565, 2015.
